Machine Structure:
- The Machine frame structure is madeup of MS material duly cladded with S.S.304 sheet.
- Contact Parts indirect contact with product/Rubber stoppers will have MOC of S.S. 316 and Non-Contact Parts MOC will be of S.S. 304/Delrin/POM.
- Infeed Conveyor guides are press fit type
- SS 304 Control Panel inside Machine frame.
- Machine Direction Left to Right.
Technical Specifications:
| Direction | Left to Right |
|---|---|
| Output Electrical Rating | 13 to 33mm (Change part included) |
| Cap Diameter | (A) 15 to 38 mm Dia. |
| Cap container Size | (B) 50 or 210 mm option for other bottle height ava (A) 0.25 hp/ 1400 RPM motor for conveyor drive |
| Electrical Rating | (B) 0.25 hp/ 1400 RPM motor for pressing device dr 230 Volts AC 50Hz |
| Power Characteristics | 2135 (1) X 925(w) X 2350 (h) |
| Overall Dimension in mm | (A) Container: star wheel back guide, feed worm |
| Change Parts Required | (B) Cap : Plunger, Delivery chute, Vibratory bowl |
Machine Salient Features:
- No bottle – No cap system.
- Cap feeder with variable speed system for feeding control of caps
- Minimum change over time
- Machine is constructed of SS-304.
- Specially designed bowl is provide to increase storage capacity of caps.
- Sealing pressure can be varied to suit different gauges and size of caps.
- Low noise level – Less power consumption
Change Parts:
- Star wheel and back guide set for changeover of different container size
- Infeed and outfeed guide set for changover of different container size
