Machine Structure:
- The Machine frame structure is made up of MS material duly cladded with S.S.304 sheet.
- Contact Parts in direct contact with Product/Rubber Stoppers will have MOC of S.S. 316 and Non-Contact Parts MOC will be of S.S. 304/Delrin/POM.
- Infeed Conveyor guides are press fit type
- SS 304 Control Panel inside Machine frame.
- Machine Direction Left to Right.
Technical Specifications:
| Direction | Left to Right |
|---|---|
| Production Speed | 20 to 40 bottle/min (depends on filling volume nature of liquid & Bottle/neck size) |
| Filling Nozzles | Four Nozzle(S.S. 316) |
| Syring Fill Range | 10ml to 500ml (with help of change parts) |
| Electrical Rating | 220V A.C. Single Phase |
| Container Size | 30mm to 100mm Diameter, Max Height 280mm |
| Overall Diamension in mm | 1830(1) X 800(w) X 1550(h) |
| Power | 2.0 HP |
Machine Salient Features:
- No Bottle – Filling stop system
- Machine is constructed of SS-304.
- All contact parts made of SS-316 material.
- Automatic in-feed and exit of bottles.
- Pneumatic Control bottle stopper.
- Reciprocating filling nozzle with self centring
- Device to avoid foaming
- Minimum change over time.
- Vibration free construction for trouble free performance.
- Automatic bottle counter system.
