Automatic Servo Sticker Labelling Machine Servo Sticker Labelling

Machine Structure:

  • The Machine frame structure is made up of MS material duly cladded with S.S.304 sheet.
  • Contact Parts in direct contact with Product/Rubber Stoppers will have MOC of S.S. 316 and Non-Contact Parts MOC will be of S.S. 304/Delrin/POM.
  • Infeed Conveyor guides are press fit type
  • SS 304 Control Panel inside Machine frame.
  • Machine Direction Left to Right.

Technical Specifications:

Direction Left to Right
Production Speed 80 ti 100 bottel/min (dipend on container and label size)
Label Accuracy ±1% (for wrap around label ±1.5 mm)
Servo Motor and Driver 750 Watt (1Nos) [Make : Delta / Panasonic / Fuji]
HMI & PLC 4.3′ (1 No) [Make : Delta / Panasonic / Fuji]
Sensor Gap sensor, Product sensor
Power Characteristics 230 Volts AC 50Hz
Overall Dimension in mm 1840 (I) x 1300 (w) x 1350 (h)
Conveyor Height 800mm + 50mm
Input Specification (A) Round Container dia.: 25 to 80mm
Label Roll Diameter (B) Label : 30 to 180mm (LT 16 to 100mm (W))
