Machine Structure:
- The Machine frame structure is made up of MS material duly cladded with S.S.304 sheet.
- Contact Parts in direct contact with product/Rubber stoppers will have MOC of S.S. 316 and Non-Contact Parts MOC will be of S.S. 304/Delrin/POM.
- Infeed Conveyor guides are press fit type
- SS 304 Control Panel inside Machine frame.
- Machine Direction Left to Right.
Technical Specifications:
| Direction | Left to Right |
|---|---|
| Output | 60 bottle/min |
| Electrical Rating | 1.5 hp |
| Power Required | 415 Volts/3 Phase/50H |
| Container Size | 25mm to 80mm Dia. |
| Fill Size | 5 gms to 60 gms |
| Overall Dimension in mm | 1500(1) X 1000(w) X 1700(h) |
Machine Salient Features:
- All contact parts made of S.S. 316 material with easy removal system for Autoclaving/Sterilization.
- Hopper can be completely dismantled for easy cleaning.
- A.C. variable frequency drive with speed control.
- No bottle-filling stop system.
- Filling accuracy + 2% depending on powder and controlled humidity bellow 30% Rh
- Low noise level-Less Power consumption
