Machine Structure:
- All Machine frame structure is madeup of MS materialduly cladded with S.S.304 sheet.
- Contact Parts indirect contact with product will have MOC of S.S. 316 and Non-Contact Parts MOC will be of S.S. 304/Delrin/POM.
- SS 304 Control Panel inside Machine frame.
- Machine Direction Left to Right.
Technical Specifications:
| Direction | Left to Right |
|---|---|
| Production Speed | 20 to 60 bottle/min (depends on filling volume nature of liquid & Bottle/neck size) |
| Filling Nozzles | Four Nozzle (SS 316) |
| Syringe Fill Range | 50ml to 1000ml |
| Servo Motor And Driver | 750 Watt(4Nos) [Make:Delta/Panasonic/Fuji] |
| HMI and PLC | 7" (1 No) [Make:Delta/Panasonic/Fuji] |
| Overall Dimension in mm | 1300(1) X 1030(w) X 1275(h) |
| Sensors | Product Sensor & Proxy Sensor |
| Rotary Gear Pump | 0.5" SS 316 Gear pump with mounting Bracket |
Machine Output:
- Filling Range-20 to 60 BPM (Bottle/Min) (Depending upon the Characteristics of the Liquid And Filling Volume)
- Accuracy - +2% (Considering Liquid Viscosity, Relative humidity and temperature)
Machine Salient Features:
- No Bottle-Filling stop System
- Machine is constructed of SS-304.
- All contact parts made of SS-316 material.
- PLC and HMI based machine control system
- Automatic in-feed and exit of bottles
- Automatic bottle counter system
- MCB for overload protection and prevention against short-circuit
